Roots blower with 10 hp motor, advanced design high profile material HT 250 cast iron. Airtight for gas delivery.
Parameter are listed below for reference:
| Model | Speed(n) | 升压△P | air flow(Q) | Shaft power | Motor | Weight | ||
| r/min | kPa | mmH2O | m3/min | kW | model | kW | kg | |
| RH10032 | 980 | 9.8 | 1000 | 6.26 | 1.9 | Y2-112M-6 | 2.2 | 393 |
| 19.6 | 2000 | 5.70 | 3.0 | Y2-132M1-6 | 4 | 425 | ||
| 29.4 | 3000 | 5.23 | 4.2 | Y2-132M2-6 | 5.5 | 434 | ||
| 39.2 | 4000 | 4.95 | 5.4 | Y2-160M-6 | 7.5 | 468 | ||
| 49 | 5000 | 4.60 | 6.5 | Y2-160M-6 | 7.5 | 468 | ||
| 58.8 | 6000 | 4.35 | 7.7 | Y2-160L-6 | 11 | 495 | ||
| 68.6 | 7000 | 4.10 | 8.8 | Y2-160L-6 | 11 | 495 | ||
| 78.4 | 8000 | 3.72 | 10.0 | Y2-160L-6 | 11 | 495 | ||
| 88.2 | 9000 | 3.19 | 11.2 | Y2-180L-6 | 15 | 545 | ||
| 98 | 10000 | 2.81 | 12.4 | Y2-180L-6 | 15 | 545 | ||
| 1100 | 9.8 | 1000 | 7.33 | 2.1 | Y2-100L2-4 | 3 | 388 | |
| 19.6 | 2000 | 6.87 | 3.4 | Y2-112M-4 | 4 | 394 | ||
| 29.4 | 3000 | 6.45 | 4.71 | Y2-132S-4 | 5.5 | 417 | ||
| 39.2 | 4000 | 6.01 | 6 | Y2-132M-4 | 7.5 | 431 | ||
| 49 | 5000 | 5.65 | 7.32 | Y2-160M-4 | 11 | 474 | ||
| 58.8 | 6000 | 5.32 | 8.63 | Y2-160M-4 | 11 | 474 | ||
| 68.6 | 7000 | 5.01 | 9.95 | Y2-160M-4 | 11 | 474 | ||
| 78.4 | 8000 | 4.80 | 11.28 | Y2-160L-4 | 15 | 495 | ||
| 1200 | 9.8 | 1000 | 8.05 | 2.31 | Y2-100L2-4 | 3 | 388 | |
| 19.6 | 2000 | 7.75 | 3.73 | Y2-132S-4 | 5.5 | 417 | ||
| 29.4 | 3000 | 7.21 | 5.14 | Y2-132S-4 | 5.5 | 417 | ||
| 39.2 | 4000 | 6.80 | 6.56 | Y2-132M-4 | 7.5 | 431 | ||
| 49 | 5000 | 6.35 | 7.99 | Y2-160M-4 | 11 | 474 | ||
| 58.8 | 6000 | 6.01 | 9.41 | Y2-160M-4 | 11 | 474 | ||
| 68.6 | 7000 | 5.82 | 10.85 | Y2-160L-4 | 15 | 495 | ||
| 78.4 | 8000 | 5.41 | 12.3 | Y2-160L-4 | 15 | 495 | ||
| 1310 | 9.8 | 1000 | 8.90 | 2.54 | Y2-100L2-4 | 3 | 388 | |
| 19.6 | 2000 | 8.42 | 4.09 | Y2-132S-4 | 5.5 | 417 | ||
| 29.4 | 3000 | 7.92 | 5.63 | Y2-132M-4 | 7.5 | 431 | ||
| 39.2 | 4000 | 7.43 | 7.17 | Y2-132M-4 | 7.5 | 431 | ||
| 49 | 5000 | 7.12 | 8.72 | Y2-160M-4 | 11 | 474 | ||
| 58.8 | 6000 | 6.87 | 10.28 | Y2-160M-4 | 15 | 474 | ||
| 68.6 | 7000 | 6.55 | 11.85 | Y2-160L-4 | 15 | 495 | ||
| 78.4 | 8000 | 6.21 | 13.43 | Y2-160L-4 | 15 | 495 | ||
| 1450 | 9.8 | 1000 | 10.02 | 2.8 | Y2-112M-4 | 4 | 394 | |
| 19.6 | 2000 | 9.55 | 4.5 | Y2-132S-4 | 5.5 | 417 | ||
| 29.4 | 3000 | 8.95 | 6.3 | Y2-132M-4 | 7.5 | 431 | ||
| 39.2 | 4000 | 8.58 | 8.0 | Y2-160M-4 | 11 | 474 | ||
| 49 | 5000 | 8.22 | 9.8 | Y2-160M-4 | 11 | 474 | ||
| 58.8 | 6000 | 7.89 | 11.5 | Y2-160L-4 | 15 | 495 | ||
| 68.6 | 7000 | 7.62 | 13.3 | Y2-160L-4 | 15 | 495 | ||
| 78.4 | 8000 | 7.35 | 15.1 | Y2-180M-4 | 18.5 | 530 | ||
| 88.2 | 9000 | 6.87 | 16.9 | Y2-180M-4 | 18.5 | 530 | ||
| 98 | 10000 | 6.30 | 18.5 | Y2-180L-4 | 22 | 550 | ||
