turbo blower for water treatment plant

HB Series is the single stage centrifugal turbo blower directly coupled with a permanent magnetic motor.

Customers can economically and environmentally get benefit from HB Series which is suitable for the customers’ applications

Applications

• Water Treatment : Aerobic microorganism digests waste by

providing air into the waste water

• Conveying powder such as chemical materials, cement, and flour to storage

• Provision of air for oxidation reaction in an absorber

• Air supply for stirring work of raw materials in the repository

• Fabrics of films for washing

• Air knife for manufacturing semiconductor, LCD/LED and continuous galvanizing line

• Braiding in Textile Mill

Model			HB 30	HB 50	HB 75	HB 100	HB 125	HB 150	HB 200	HB 250	HB 300	HB 400
Type			Single Impeller								Dual Impeller
Discharge Pressure			Flow rate (CMM/CFM) : 1 atm, 20℃(68℉), 65% / Tolerance= + - 5 %
CMM @ 0.6 bar			20	34	51	69	85	105	140	164	210	280
CFM @ 8.7 psi			700	1,200	1,800	2,450	3,000	3,700	4,950	5,800	7,400	9,900
CMM @ 0.8bar			17	28	42	55	70	84	109	135	164	218
CFM @ 11.6 psi			600	1,000	1,500	1,950	2,500	3,000	3,850	4,750	5,800	7,700
CMM @ 1bar			-	-	34	45	-	67	87	104	133	174
CFM @ 14.5 psi			-	-	1,200	1,600	-	2,400	3,100	3,650	4,700	6,150
Shaft Power (HP)			30	50	75	100	125	150	200	250	300	400
Exhaust Pipe			150A	150A	200A	200A	200A	300A	300A	300A	400A	500A
Dimension	W	mm	700	700	850	850	850	900	900	900	1,200	1,500
	W	Inch	30	30	33	33	33	35	35	35	48	60
	L	mm	1,300	1,300	1,500	1,500	1,500	1,800	1,800	1,800	2,200	2,300
	L	Inch	51	51	59	59	59	71	71	71	87	87
	H	mm	1,100	1,100	1,400	1,400	1,400	1,650	1,650	1,650	2,000	2,000
	H	Inch	43	43	55	55	55	65	65	65	79	79
Weight (kg)			500	500	700	700	700	900	900	900	1,200	1,400
