RH35073S BLOWER

RH35073S ROOTS BLOWER

RH roots blower reactive silencer

RH roots blower canopy
| Model | Speed R.P.M | △P | Air flow(Q) | Shaft power | Motor | Weight | |
| r/min | kPa | m3/min | kW | model | kW | kg | |
| RH35073 | 740 | 9.8 | 91.4 | 27.7 | Y2-250M-8 | 30 | 3503 |
| 19.6 | 88.2 | 44.2 | Y2-315S-8 | 55 | 4195 | ||
| 29.4 | 86.3 | 60.7 | Y2-315M-8 | 75 | 4305 | ||
| 39.2 | 84.4 | 77.2 | Y2-315L1-8 | 90 | 4375 | ||
| 49 | 83.1 | 93.8 | Y2-315L2-8 | 110 | 4445 | ||
| 58.8 | 82.3 | 110.3 | Y2-355M1-8 | 132 | 4825 | ||
| 68.6 | 81.5 | 126.9 | Y2-355M2-8 | 160 | 4925 | ||
| 78.4 | 80.7 | 143.5 | Y2-355M2-8 | 160 | 4925 | ||
| 88.2 | 79.8 | 160.1 | Y2-355L-8 | 200 | 5340 | ||
| 98 | 79.2 | 176.7 | Y2-355L-8 | 200 | 5340 | ||
| 820 | 9.8 | 102 | 30.4 | Y2-250M-6 | 37 | 3550 | |
| 19.6 | 98.8 | 48.7 | Y2-280M-6 | 55 | 3720 | ||
| 29.4 | 96.9 | 67 | Y2-315S-6 | 75 | 3857 | ||
| 39.2 | 95 | 85.3 | Y2-315L1-6 | 110 | 4230 | ||
| 49 | 93.7 | 103.6 | Y2-315L2-6 | 132 | 4330 | ||
| 58.8 | 92.9 | 122 | Y2-315L2-6 | 132 | 4330 | ||
| 68.6 | 92.1 | 140.4 | Y2-355M1-6 | 160 | 4765 | ||
| 78.4 | 91.3 | 158.7 | Y2-355M2-6 | 200 | 4885 | ||
| 900 | 9.8 | 112.6 | 33 | Y2-250M-6 | 37 | 3550 | |
| 19.6 | 109.4 | 53.1 | Y2-315S-6 | 75 | 3857 | ||
| 29.4 | 107.5 | 73.1 | Y2-315M-6 | 90 | 3897 | ||
| 39.2 | 105.6 | 93.2 | Y2-315L1-6 | 110 | 4230 | ||
| 49 | 104.3 | 113.3 | Y2-315L2-6 | 132 | 4330 | ||
| 58.8 | 103.5 | 133.3 | Y2-355M1-6 | 160 | 4765 | ||
| 68.6 | 102.7 | 153.4 | Y2-355M2-6 | 200 | 4885 | ||
| 78.4 | 101.9 | 173.4 | Y2-355M2-6 | 200 | 4885 | ||
| 980 | 9.8 | 123.3 | 35.6 | Y2-280S-6 | 45 | 3645 | |
| 19.6 | 120 | 57.5 | Y2-315S-6 | 75 | 4185 | ||
| 29.4 | 118.2 | 79.3 | Y2-315M-6 | 90 | 4285 | ||
| 39.2 | 116.3 | 101.1 | Y2-315L1-6 | 110 | 4365 | ||
| 49 | 115 | 122.7 | Y2-315L2-6 | 132 | 4425 | ||
| 58.8 | 114.3 | 144.5 | Y2-355M1-6 | 160 | 4825 | ||
| 68.6 | 113.5 | 166.6 | Y2-355M2-6 | 200 | 4925 | ||
| 78.4 | 112.6 | 188.8 | Y2-355L-6 | 250 | 5350 | ||
| 88.2 | 111.8 | 211 | Y2-355L-6 | 250 | 5350 | ||
| 98 | 111.2 | 233.1 | Y2-355L-6 | 250 | 5350 | ||
| 1050 | 9.8 | 132.6 | 37.9 | Y2-225M-4 | 45 | 3505 | |
| 19.6 | 129.3 | 61.5 | Y2-280S-4 | 75 | 3695 | ||
| 29.4 | 127.5 | 85.1 | Y2-315S-4 | 110 | 4115 | ||
| 39.2 | 125.6 | 108.7 | Y2-315M-4 | 132 | 4235 | ||
| 49 | 124.3 | 132.3 | Y2-315L1-4 | 160 | 4295 | ||
| 58.8 | 123.6 | 155.9 | Y2-315L2-4 | 200 | 4455 | ||
| 68.6 | 122.8 | 179.5 | Y2-315L2-4 | 200 | 4455 | ||
| 78.4 | 121.9 | 203.1 | Y2-355M-4 | 250 | 4855 | ||
| 1120 | 9.8 | 141.9 | 40.2 | Y2-225M-4 | 45 | 3505 | |
| 19.6 | 138.6 | 65.4 | Y2-280S-4 | 75 | 3695 | ||
| 29.4 | 136.8 | 90.6 | Y2-315S-4 | 110 | 4115 | ||
| 39.2 | 134.9 | 115.8 | Y2-315M-4 | 132 | 4235 | ||
| 49 | 133.6 | 141.1 | Y2-315L1-4 | 160 | 4295 | ||
| 58.8 | 132.9 | 166.3 | Y2-315L2-4 | 200 | 4455 | ||
| 68.6 | 132.1 | 191.5 | Y2-355M-4 | 250 | 4855 | ||
| 78.4 | 131.2 | 216.7 | Y2-355M-4 | 250 | 4855 | ||
| 1190 | 9.8 | 151.2 | 42.4 | Y2-225M-4 | 55 | 3510 | |
| 19.6 | 147.9 | 69.2 | Y2-280S-4 | 75 | 3695 | ||
| 29.4 | 146.1 | 96 | Y2-315S-4 | 110 | 4115 | ||
| 39.2 | 144.2 | 122.8 | Y2-315L1-4 | 160 | 4295 | ||
| 49 | 142.9 | 149.6 | Y2-315L2-4 | 200 | 4455 | ||
| 58.8 | 142.2 | 176.4 | Y2-315L2-4 | 200 | 4455 | ||
| 68.6 | 141.4 | 203.2 | Y2-355M-4 | 250 | 4855 | ||
| 1250 | 9.8 | 160.5 | 44.6 | Y2-250M-4 | 55 | 3510 | |
| 19.6 | 157.2 | 72.7 | Y2-280M-4 | 90 | 3785 | ||
| 29.4 | 155.4 | 100.8 | Y2-315S-4 | 110 | 4115 | ||
| 39.2 | 153.5 | 129 | Y2-315L1-4 | 160 | 4295 | ||
| 49 | 152.2 | 157.1 | Y2-315L2-4 | 200 | 4455 | ||
| 58.8 | 151.5 | 185.2 | Y2-355M-4 | 250 | 4855 | ||
| 68.6 | 150.7 | 213.3 | Y2-355M-4 | 250 | 4855 | ||
RH35073S roots type blower are heavy duty fabricated, robust structure with serene performance.
RH35073S blower are widely used in tissure making industry for suction vapor as an vacuum pump, the discharge are directly to the atmosphere.
RH35073S roots blower with 250kw motor, driven by V-belts with safety guard. The outlet silencer are adopted reactive silencer, which can achive noise abatement to a certain level.
