Product Description

Brief info.
Products name RH08023 roots blower package with acoustic enclosure
Brand:RH
Place of origin:Nantong China
Usage:water treatment industry for aeration,gas delivery,industrial air source;
Features:Three lobed rugged structure and high flow capacity
Pressure rise:up to 78kpa
Cooling :natural air coolilng
color: blue or silver, the color can be customized by customer
Noise: less than 77dB,1m from acoustic enclosure
Bore:DN80;3inch
Lubrication:oil
Motor:3kw-11kw
Rated Voltage:380V
Flow capacity:4.5-7m3/min
Seal:piston Ring

Warranty:12 months since first startup or 18 months since shipment whichever occurs first

Material and feature:
A triple-lobe blower blower
A suction filter-muffler.
A frame which is also a discharge silencer, made from A3 steel metal
Activation through an electric motor and transmission by belts and pulleys with a taper-lock.
Steel transmission protection, as well as a soundproof cabinet.
A safety valve, able to release all the air in the event of excessive pressure..
A check valve which protects the blower group against blowback, through the discharge pipe.
The connection between the blower group and the system is by flange
Every cabinet in the group is supported on vibration damping, cushioned feet.
Oil filling and draining system.

R-BOX Intelligent Online Roots Blower, a municipal science and technology planned product, was developed to optimize the acoustic environment and control experience. Detachable remote control cabinet, real-time 5G communication monitoring, management and control. Positive pressure dust-free silencing room design, efficient heat dissipation, noise prevention, and more stable operation.
Features:
1. forklift port at the baseframe, easy installation and operation
2.Noise aborbed filter to reduce noise level, less than 70dB 1 meter distance from acoustic enclosure
3.authentic apperance design, easy operation
4. forced ventilation to reduce temperature rise
5.gate valve to availabe to adjust the air flow capacity
6.variable frequency motor optional for variable flow range

Model	Speed(n)	△P		Flow(Q)	Shaft Power	Motor		weight
Model	r/min	kPa	mmH2O	m3/min	kW	Model	power kW	kg
RH08023	1650	9.8	1000	5.70	1.9	Y2-100L1-4	2.2	254
		19.6	2000	5.31	2.8	Y2-100L2-4	3	258
		29.4	3000	5.11	3.8	Y2-112M-4	4	264
		39.2	4000	4.92	4.7	Y2-132S-4	5.5	287
		49	5000	4.62	5.6	Y2-132M-4	7.5	301
		58.8	6000	4.33	6.6	Y2-132M-4	7.5	301
	1800	9.8	1000	6.29	2.1	Y2-100L2-4	3	258
		19.6	2000	5.90	3.1	Y2-112M-4	4	264
		29.4	3000	5.60	4.2	Y2-132S-4	5.5	287
		39.2	4000	5.41	5.2	Y2-132M-4	7.5	301
		49	5000	5.21	6.2	Y2-132M-4	7.5	301
		58.8	6000	5.01	7.3	Y2-160M-4	11	344
	1950	9.8	1000	6.78	2.2	Y2-100L2-4	3	258
		19.6	2000	6.49	3.4	Y2-112M-4	4	264
		29.4	3000	6.19	4.6	Y2-132S-4	5.5	287
		39.2	4000	6.00	5.7	Y2-132M-4	7.5	301
		49	5000	5.80	6.9	Y2-132M-4	7.5	301
		58.8	6000	5.60	8.0	Y2-160M-4	11	344
	2100	9.8	1000	7.37	2.4	Y2-100L2-4	3	258
		19.6	2000	7.08	3.7	Y2-132S-4	5.5	287
		29.4	3000	6.88	5.0	Y2-132S-4	5.5	287
		39.2	4000	6.49	6.2	Y2-132M-4	7.5	301
		49	5000	6.19	7.5	Y2-160M-4	11	344
		58.8	6000	6.00	8.7	Y2-160M-4	11	344
