RH Roots Blower is exquisite designed and fabricated according to the national and industry standards by our rich experienced technicians . we are one of the industrial benchmark drafters in roots blower industry.
Place of origin:China
Port:Shanghai
Model: RH10032S
Diameter: DN100
Flow Capacity:3.5-12m3/min
Pressure:up to 78kpa
Noise:less than 80dB(A)
cooling type: water cooling or air cooling
motor:15kw-22kw IP54 380V/415V 50HZ
Accessories: inlet silencer, outlet silencer, check valve, flexible joint,pressure gauge
connection: direct coupling or V-belt driven
Q:Are you direct manufacturer or trading company?
A. We have our own factory and international department.
We produce and sell all by ourselves.
Q: How about the price?
A.The price is negotiable. It can be changed according to your quantity or packaging.When you are making an inquiry, please let us know all the details.
Q.Do you have an extended warranty?
A.Yes,all products provide a one-year guarantee quality after-sales service.
Packing
Packing
| Model | Speed(n) | △P |
air flow(Q) |
Shaft power | Motor | Weight | ||
| r/min | kPa | mmH2O | m3/min | kW | model | kW | kg | |
| RH10032 | 980 | 9.8 | 1000 | 6.26 | 1.9 | Y2-112M-6 | 2.2 | 393 |
| 19.6 | 2000 | 5.70 | 3.0 | Y2-132M1-6 | 4 | 425 | ||
| 29.4 | 3000 | 5.23 | 4.2 | Y2-132M2-6 | 5.5 | 434 | ||
| 39.2 | 4000 | 4.95 | 5.4 | Y2-160M-6 | 7.5 | 468 | ||
| 49 | 5000 | 4.60 | 6.5 | Y2-160M-6 | 7.5 | 468 | ||
| 58.8 | 6000 | 4.35 | 7.7 | Y2-160L-6 | 11 | 495 | ||
| 68.6 | 7000 | 4.10 | 8.8 | Y2-160L-6 | 11 | 495 | ||
| 78.4 | 8000 | 3.72 | 10.0 | Y2-160L-6 | 11 | 495 | ||
| 88.2 | 9000 | 3.19 | 11.2 | Y2-180L-6 | 15 | 545 | ||
| 98 | 10000 | 2.81 | 12.4 | Y2-180L-6 | 15 | 545 | ||
| 1100 | 9.8 | 1000 | 7.33 | 2.1 | Y2-100L2-4 | 3 | 388 | |
| 19.6 | 2000 | 6.87 | 3.4 | Y2-112M-4 | 4 | 394 | ||
| 29.4 | 3000 | 6.45 | 4.71 | Y2-132S-4 | 5.5 | 417 | ||
| 39.2 | 4000 | 6.01 | 6 | Y2-132M-4 | 7.5 | 431 | ||
| 49 | 5000 | 5.65 | 7.32 | Y2-160M-4 | 11 | 474 | ||
| 58.8 | 6000 | 5.32 | 8.63 | Y2-160M-4 | 11 | 474 | ||
| 68.6 | 7000 | 5.01 | 9.95 | Y2-160M-4 | 11 | 474 | ||
| 78.4 | 8000 | 4.80 | 11.28 | Y2-160L-4 | 15 | 495 | ||
| 1200 | 9.8 | 1000 | 8.05 | 2.31 | Y2-100L2-4 | 3 | 388 | |
| 19.6 | 2000 | 7.75 | 3.73 | Y2-132S-4 | 5.5 | 417 | ||
| 29.4 | 3000 | 7.21 | 5.14 | Y2-132S-4 | 5.5 | 417 | ||
| 39.2 | 4000 | 6.80 | 6.56 | Y2-132M-4 | 7.5 | 431 | ||
| 49 | 5000 | 6.35 | 7.99 | Y2-160M-4 | 11 | 474 | ||
| 58.8 | 6000 | 6.01 | 9.41 | Y2-160M-4 | 11 | 474 | ||
| 68.6 | 7000 | 5.82 | 10.85 | Y2-160L-4 | 15 | 495 | ||
| 78.4 | 8000 | 5.41 | 12.3 | Y2-160L-4 | 15 | 495 | ||
| 1310 | 9.8 | 1000 | 8.90 | 2.54 | Y2-100L2-4 | 3 | 388 | |
| 19.6 | 2000 | 8.42 | 4.09 | Y2-132S-4 | 5.5 | 417 | ||
| 29.4 | 3000 | 7.92 | 5.63 | Y2-132M-4 | 7.5 | 431 | ||
| 39.2 | 4000 | 7.43 | 7.17 | Y2-132M-4 | 7.5 | 431 | ||
| 49 | 5000 | 7.12 | 8.72 | Y2-160M-4 | 11 | 474 | ||
| 58.8 | 6000 | 6.87 | 10.28 | Y2-160M-4 | 15 | 474 | ||
| 68.6 | 7000 | 6.55 | 11.85 | Y2-160L-4 | 15 | 495 | ||
| 78.4 | 8000 | 6.21 | 13.43 | Y2-160L-4 | 15 | 495 | ||
| 1450 | 9.8 | 1000 | 10.02 | 2.8 | Y2-112M-4 | 4 | 394 | |
| 19.6 | 2000 | 9.55 | 4.5 | Y2-132S-4 | 5.5 | 417 | ||
| 29.4 | 3000 | 8.95 | 6.3 | Y2-132M-4 | 7.5 | 431 | ||
| 39.2 | 4000 | 8.58 | 8.0 | Y2-160M-4 | 11 | 474 | ||
| 49 | 5000 | 8.22 | 9.8 | Y2-160M-4 | 11 | 474 | ||
| 58.8 | 6000 | 7.89 | 11.5 | Y2-160L-4 | 15 | 495 | ||
| 68.6 | 7000 | 7.62 | 13.3 | Y2-160L-4 | 15 | 495 | ||
| 78.4 | 8000 | 7.35 | 15.1 | Y2-180M-4 | 18.5 | 530 | ||
| 88.2 | 9000 | 6.87 | 16.9 | Y2-180M-4 | 18.5 | 530 | ||
| 98 | 10000 | 6.30 | 18.5 | Y2-180L-4 | 22 | 550 | ||
