A rotary positive blower, sometimes called a Positive Displacement, or PD blower, is a machine that "pushes" a relatively constant volume of the gas handled at the inlet through the discharge. It doesn't internally compress the gas, so it isn't considered a compressor. The amount of gas the machine handles is fixed by the configuration of the casing and rotating parts.
Basic Info.
Specifications:
| Model | RH12542S/ RH10032/RH08023 |
| Air capacity flow | 5m3/Min-25m3/min |
| Discharge differential pressure | 9.8-78.KPA |
| Rotary speed | 980rpm-1600rpm |
| Motor type |
15KW-37KW 380/400/415/440V, 3PHASES, 50/60HZ |
| Motor brand |
Standard:Jianghuai or Wannan motor Siemens,TECO, ABB motor for your option |
| Installation type |
Standard: horizontal type. |
| N.W. of blower with motor | 720kg/500kg/300KG |
| Packing size Approx. | 1500mm*1050mm*1750mm (length*width*height) |
| Features |
|
Company Info.
Nantong Rongheng Environmental Equipment Co.,Ltd. is a state-level high-tech enterprise specialized in manufacturing environmental protection equipment and integrating R&D,manufacturing ,sales and technical services.Leading products mainly include Roots type blower,Air foil suspension blower,MVR compressor,Multistage centrifugal blower,Rotary blower etc. With technical competence,advanced design methods,state of the art processing equipment,our products has successfully broken through the high energy consumption and big noise bottleneck ,which making us outstanding in this industry.
| Model | Speed(n) | △P | Inlet Capacity(Q) | Air flow(Q) | shaft power | motor | weight | |
| r/min | kPa | m3/min | CFM | kW | model | kW | kg | |
| RH12542 | 980 | 9.8 | 13.1 | 464.1 | 4.1 | Y2-132M2-6 | 5.5 | 624 |
| 19.6 | 12.4 | 436.6 | 6.3 | Y2-160M-6 | 7.5 | 658 | ||
| 29.4 | 11.8 | 415.9 | 8.5 | Y2-160L-6 | 11 | 685 | ||
| 39.2 | 11.2 | 393.6 | 10.7 | Y2-180L-6 | 15 | 735 | ||
| 49 | 10.6 | 373.6 | 12.9 | Y2-180L-6 | 15 | 735 | ||
| 58.8 | 10.2 | 360.3 | 15.1 | Y2-200L1-6 | 18.5 | 760 | ||
| 68.6 | 9.8 | 346.2 | 17.2 | Y2-200L1-6 | 18.5 | 760 | ||
| 78.4 | 9.3 | 328.4 | 19.5 | Y2-200L2-6 | 22 | 790 | ||
| 88.2 | 8.4 | 296.5 | 21.7 | Y2-225M-6 | 30 | 832 | ||
| 98 | 7.9 | 278.0 | 23.9 | Y2-225M-6 | 30 | 832 | ||
| 1100 | 9.8 | 15.1 | 533.0 | 4.6 | Y2-132S-4 | 5.5 | 607 | |
| 19.6 | 14.3 | 505.9 | 7.1 | Y2-160M-4 | 11 | 664 | ||
| 29.4 | 13.6 | 481.1 | 9.5 | Y2-160M-4 | 11 | 664 | ||
| 39.2 | 13.2 | 467.4 | 12.0 | Y2-160L-4 | 15 | 685 | ||
| 49 | 12.7 | 449.2 | 14.6 | Y2-180M-4 | 18.5 | 720 | ||
| 58.8 | 12.3 | 434.4 | 17.1 | Y2-180M-4 | 18.5 | 720 | ||
| 68.6 | 11.9 | 420.7 | 19.7 | Y2-180L-4 | 22 | 740 | ||
| 78.4 | 11.2 | 393.6 | 22.3 | Y2-200L-4 | 30 | 810 | ||
| 1200 | 9.8 | 16.4 | 578.2 | 5.0 | Y2-132M-4 | 7.5 | 621 | |
| 19.6 | 15.7 | 555.2 | 7.7 | Y2-160M-4 | 11 | 664 | ||
| 29.4 | 15.4 | 543.0 | 10.4 | Y2-160L-4 | 15 | 685 | ||
| 39.2 | 14.7 | 519.3 | 13.1 | Y2-160L-4 | 15 | 685 | ||
| 49 | 14.3 | 505.9 | 15.8 | Y2-180M-4 | 18.5 | 720 | ||
| 58.8 | 13.8 | 486.3 | 18.5 | Y2-180L-4 | 22 | 740 | ||
| 68.6 | 13.4 | 473.7 | 21.3 | Y2-200L-4 | 30 | 810 | ||
| 78.4 | 12.7 | 449.2 | 24.1 | Y2-200L-4 | 30 | 810 | ||
| 1310 | 9.8 | 18.1 | 638.6 | 5.5 | Y2-132M-4 | 7.5 | 621 | |
| 19.6 | 17.4 | 614.5 | 8.4 | Y2-160M-4 | 11 | 664 | ||
| 29.4 | 16.7 | 591.2 | 11.4 | Y2-160L-4 | 15 | 685 | ||
| 39.2 | 16.2 | 572.7 | 14.4 | Y2-180M-4 | 18.5 | 720 | ||
| 49 | 15.6 | 551.9 | 17.4 | Y2-180M-4 | 18.5 | 720 | ||
| 58.8 | 15.2 | 538.2 | 20.4 | Y2-180L-4 | 22 | 740 | ||
| 68.6 | 14.9 | 527.1 | 23.5 | Y2-200L-4 | 30 | 810 | ||
| 78.4 | 14.3 | 504.1 | 26.6 | Y2-200L-4 | 30 | 810 | ||
| RH12542 | 1450 | 9.8 | 20.1 | 707.9 | 6.1 | Y2-132M-4 | 7.5 | 621 |
| 19.6 | 19.4 | 685.7 | 9.5 | Y2-160M-4 | 11 | 664 | ||
| 29.4 | 18.9 | 667.2 | 12.8 | Y2-160L-4 | 15 | 685 | ||
| 39.2 | 18.3 | 644.9 | 16.2 | Y2-180M-4 | 18.5 | 720 | ||
| 49 | 17.7 | 626.4 | 19.5 | Y2-180L-4 | 22 | 740 | ||
| 58.8 | 17.4 | 614.2 | 22.9 | Y2-200L-4 | 30 | 810 | ||
| 68.6 | 17.1 | 604.2 | 26.3 | Y2-200L-4 | 30 | 810 | ||
| 78.4 | 16.7 | 589.3 | 29.7 | Y2-225S-4 | 37 | 824 | ||
| 88.2 | 15.9 | 559.7 | 33.1 | Y2-225S-4 | 37 | 824 | ||
| 98 | 15.0 | 530.0 | 36.6 | Y2-225M-4 | 45 | 860 | ||
| 1600 | 9.8 | 22.3 | 786.5 | 6.9 | Y2-160M-4 | 11 | 664 | |
| 19.6 | 21.5 | 758.0 | 10.8 | Y2-160L-4 | 15 | 685 | ||
| 29.4 | 20.8 | 735.7 | 14.7 | Y2-180M-4 | 18.5 | 720 | ||
| 39.2 | 20.4 | 719.8 | 18.6 | Y2-180L-4 | 22 | 740 | ||
| 49 | 19.9 | 702.4 | 22.5 | Y2-200L-4 | 30 | 810 | ||
| 58.8 | 19.2 | 677.8 | 26.5 | Y2-200L-4 | 30 | 810 | ||
| 68.6 | 19.3 | 682.7 | 30.3 | Y2-225S-4 | 37 | 824 | ||
